HAKRC F7220 V2 Flight Controller

Physical Specifications:

• Dimensions: 30×30mm (20×20mm mounting holes)

• Package Dimensions: 64×64×35mm

• Input Voltage: 2-6S LiPo

• Net Weight: 6g

• Package Weight: 38.5g

Flight Controller Parameters:

• CPU: STM32F722RET6

• IMU: ICM42688 Dual Gyroscope

• OSD: AT7456E

• Barometer: Integrated

• Blackbox: 16MB

• BEC: 5V/2.5A & 10V/2A

• LED: Supports external programmable LEDs

• Sensors: Built-in current sensor

• Firmware Version: HAKRCF722V2

• Receiver Support: Frsky/Futaba/Flysky/TBS Crossfire/DSMX/DSM2

Packing list:

1x F7220V2 flight controller

4x M2 shock absorber

1x 8 cables

1x DJI FPV cable

1x Dajiang O3 aviation crew three in one cable

1x instruction manual
