Features:
1. The PCB adopts high-end 8-layer 3oZ thickened copper skin, which has stronger overcurrent capacity and good heat dissipation.
2. The MOS adopts a 40V high-current-resistant MOS, which has a long life and strong load capacity.
3. Adopt industrial-grade LDO, high temperature resistance.
4. Adopt high-quality Japanese Murata capacitors, with strong filtering performance
Size: 56*52mm
Product net weight: 33g
ESC parameters：
- ESC firmware：BLHeliSuite16714902A_Beta
- Protocol support: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
- Input voltage: 2S-8S Lipo
- Continuous current: 90A
- Peak current: 100A
